Die DURIS E 5 kombiniert hohe Effizienz und einen weiten Abstrahlwinkel in einer kompakten Bauform (5.6 mm x 3.0 mm). Speziell für Anwendungen mit besonders homogener Lichtverteilung kann die DURIS E 5 mit ihrer Leistung auf Systemebene überzeugen.
- Farbe: warm- und neutralweiß; CRI (min.) = 80; CRI (typ.) = 85; CTR = 5000 K
- Optischer Wirkungsgrad (typ.): 112 lm/W (warm- und neutralweiß) bei 5000 K
- ESD - Festigkeit: ESD-sicher bis 5 kV nach JESD22-A114-F
- Lichtstromerhaltung: Testergebnisse nach IESNA LM-80 verfügbar
English version
Product description
The DURIS E 5 combines high efficacy and a wide beam angle into a compact format (5.6 mm x 3.0 mm). This is key to homogeneous illumination applications where the DURIS E 5 never fails to impress with its performance on system level
Features
- Package: white SMT package, colored diffused silicone resin
- Technology: InGaN on Sapphire
- Viewing angle at 50 % I V
: 120°
- Color: warm and neutral white; CRI (min.) = 80; CRI (typ.) = 85; CTR = 5000 K
- Optical efficiency (typ.): 112 lm/W (warm and neutral white) at 5000 K
- ESD - withstand voltage: up to 5 kV acc. to JESD22-A114-F
- Lumen Maintenance: Test results according to IESNA LM-80 available
Technical Specifications
LED data:
- Type: LC WJDSH.EC
- Housing type: white SMT housing, coloured diffuse silicone encapsulation
- Typical luminous flux: 45-60 lumen at 120 mA
- Typical colour temperature: 4000 K
- beam angle: 120
- optical efficiency: 130 lumen/watt
- max. forward current: 180 mA
- typ. forward voltage: 3.1 V
Board data:
- Type: metal core board
- Shape: star
- Size (diameter): around 20 mm
- Connection: 4 pads (2 each anode and cathode)
- Thickness: around 1.7 mm
- Base: 1.5 mm aluminium
- Dielectric: 0.1 mm with 1.8 W/mK Thermal conductivity
- Electr. conduction: 35 µm copper
- Surface: HAL lead-free
- Solder resist: white glossy
Item features
Item condition: New: New, unused and undamaged item in unopened original packaging.
